1. Pump Drives Access in Pumps Piping & Design
According to Pumps Piping guidelines, what is required for pump drives?
Explanation: Pump drives should have clear access according to Pumps Piping guidelines.
2. Pump Suction Piping
How should pump suction piping be arranged according to Pumps Piping?
Explanation: Pump suction piping should be as short as possible to avoid vapor pockets according to Pumps Piping.
3. Reducers at Pump Suction Nozzle
What type of reducers should be used at the pump suction nozzle according to Pumps Piping?
Explanation: Reducers at the pump suction nozzle should be eccentric type with flat side up to avoid the accumulation of gas pockets.
4. End Suction Pumps
For end suction pumps, what is the recommendation regarding elbows directly connected to the suction flange?
Explanation: For end suction pumps, elbows should not be directly connected to the suction flange. A straight piece of minimum 3 times the line size should be provided at the suction nozzle.
5. Pump Discharge Check Valve
Where should the drain connection be placed if a pump discharge check valve is installed in vertical lines according to Pumps Piping?
Explanation: The drain connection for a pump discharge check valve in vertical lines should be as close as possible downstream of the valve according to Pumps Piping.
6. Strainers on Pump Suction Piping
What type of strainers should be used on pump suction piping for sizes 2″ and above?
Explanation: T-type strainers should be used on pump suction piping for sizes 2″ and above according to Pumps Piping.
7. Strainers on Pump Suction Lines Below 2″
What type of strainers should be used for pump suction lines below 2”?
Explanation: Y-type strainers should be used for pump suction lines below 2” according to Pumps Piping.
8. Pump Strainer Installation
Where should pump strainers be installed according to Pumps Piping?
Explanation: Pump strainers should be installed at ground level, except for top suction pumps according to Pumps Piping.
9. Small Bore Piping Connected to Pump
What provision should be made for small bore piping connected to the pump according to Pumps Piping?
Explanation: All small bore piping connected to the pump should have provision for break up flanges for removal according to Pumps Piping.
10. Pump Discharge Routing
According to Pumps Piping, how should pump discharge be routed?
Explanation: Pump discharge should be preferably routed away from the pump rather than towards the motor side according to Pumps Piping.
